MINI LiDAR AS-11C
| Ürün Kodu : | AS-11C |
| Kategori : | Mesafe sensörleri, Lidar tarayıcıları |
| Etiketler : | AS-11C |
| Stok : | Stokta Var |
| Model | AS-11C |
| Working principle | TOF |
| Optical working principle | Diffuse reflection |
| Light Source | Infrared laser (905nm) |
| Laser spot exit aperture | 10mm |
| Scanning angle | 360 ° |
| Scanning Angle Resolution | 0.5 ° |
| Measuring Range | 0.1m to 20m |
| Operating Voltage | 12V~28V DC |
| Power Consumption | 4.5W@DC 24V |
| Communication | Ethernet, rate: 10/100 Mbps; Network protocol: TCP/P: Functions: device configuration/measurement data output/monitoring signal output |
| Operating temperature | - 10 ℃ ~ + 45 ℃ |
| Storage Temperature | - 30 ℃ ~ + 70 ℃ |
| Operating humidity | 93% and + 40 ℃, 2 h (GB/T2423, 3) |
| Ambient Illumination | 70000 Lux or less |
| Vibration Resistance | GB/T 2423,10 |
| Enclosure rating | IP65(GB4208~2008) |
| Connection | Cable connection |
| Dimension | 86.0 * 85.0 * 59.5 (mm) |
| Material | Aluminum alloy |
| Weight | 0.5 kg |
| Accessories | Power supply, RJ45 socket, leads |
| Safety class | Class 1 (GB 7247.1-2012, eye safety) |
| Laser spot emission angle | 10.0 (H) x 2.0 (V) mrad |
| Scanning Frequency | 360 ° |
| System error (typical) | ±5cm (1m to 15m) |
| Statistical error(1a) | ±2cm (1m~15m) |
| Indicator | Quantity: 2; Definition: ERR [device alarm: fault/abnormal, transmission mask dirty/blocked, high and low temperature, fog]; HTR [operating status indicator: detection signal/self-learning] |
