EOS Series EOS-150NPIO
| Ürün Kodu : | EOS-150NPIO |
| Kategori : | Mesafe sensörleri, Lazer mesafe sensörleri |
| Etiketler : | EOS-150NPIO |
| Stok : | Stokta Var |
| Model | EOS-150NPIO |
| Working principle | Triangulation |
| Sensing method | Diffuse |
| Housing. | Rectangular |
| Sensing distance | 25-150mm |
| Operation model | Light.on / Dark.on switchable |
| Output model | NPN / PNP / IO-Link / Push-pull switchable |
| Response time | 0.5ms/5ms/20ms switchable |
| Response frequency | 1000Hz |
| Repeatability. | <0.5% |
| Linearity. | <1% |
| Hysteresis. | - |
| External input | Tuning: ON when ≥35ms, OFF when ≥35ms.Light projection stop: ON when ≥2ms, OFF when ≥20ms. |
| Operating voltage | 10~30V DC ±10% |
| Power consumption | <500mW |
| Voltage drop | <1.5V |
| Load current | ≤100mA |
| Operating temperature | -10℃~50℃ (No Freezing) |
| Storage temperature | -25℃~75℃ (No Freezing) |
| Operating humidity | 35%~85% RH (No Condensation) |
| Storage humidity | 35%~95% RH (No Condensation) |
| Ambient illumination | Incandescent lamp≤5000Lux; Sunlight≤10000Lux |
| Shock resistance | 1000m/s², 6 times each in X/Y/Z directions |
| Reflector. | - |
| Vibration resistance | 10～55Hz, 1.5mm double amplitude for 2 hours each in X/Y/Z directions |
| Max tightening torque | 0.5N.m |
| Connection. | 2m/4-wire cable |
| Dimensions. | 41.8x29.7x15.0mm |
| Housing material | SUS316L |
| Detectable deviation | 25~100mm: 1.5mm; 100~150mm: 3mm |
| Display resolution | 25-100mm: 0.1mm; 100-150mm: 0.2mm |
| Light source | Red Laser (650nm, Class 1) |
| Weight. | Approx. 95g |
| Spot size | Approx. 2.3x0.9mm |
| Indicator. | Power: Green; Output: Orange; Display: OLED |
| Timer. | OFF/ON-Delay/OFF-Delay/Single Pulse |
| Insulation resistance | - |
| Dielectric strength. | - |
| Protection circuit | Reverse polarity protection/Surge protection/Overcurrent protection |
| Enclosure rating | IP67 |
| Accessories. | - |
